Photovoltaic optimizer 600W

Product Item：SUNWIN-600W

Max Input Power:600W

Max Operating volt:7-60V

Max input currernt:16A

CE/EMC/FCC APPROAL

Description

Solar optimizer 600W

Description:

More power starts on the roof with Solar Power Optimizers. By mitigating shading, preventing clipping, and decreasing mismatch loss, power optimizers help get more energy from each panel while allowing panel level monitoring for more control and flexibility.

Function:

Increase the efficiency of solar panel power generation by 10% ~ 30%.
Highly compatible with inverters
Improve the power generation efficiency of photovoltaic modules when they are affected by shadow problems.

Specification

Brand NONE	Place of Origin China	Product name Solar Power Optimizer
Color Black	Maximum System Voltage 1500Vdc	Rated Input Power 600W
Range of Input Voltage 7V~60V	Range of MPPT Voltage 7V~60V	Maximum Input Current 16A
Peak Eficiency 99.50%	Operating Temperature -40 to 85C	Enclosure Type IP68
