  • 1000V UL 2pfg 1169 Solar cable UL approval
  • 1000V UL 2pfg 1169 Solar cable UL approval
  • 1000V UL 2pfg 1169 Solar cable UL approval
  • 1000V UL 2pfg 1169 Solar cable UL approval
1000V UL 2pfg 1169 Solar cable UL approval1000V UL 2pfg 1169 Solar cable UL approval1000V UL 2pfg 1169 Solar cable UL approval1000V UL 2pfg 1169 Solar cable UL approval

1000V UL 2pfg 1169 Solar cable UL approval

  • Product Item:PV1-F 1169
  • Tinned copper
  • UL APPROVAL
  • XLPO/XLPE
  • 2Pfg 1169 PV cable , Solar cable 4mm2 6mm2
    Inquiry Send Email

    Description

    1000V UL 2pfg 1169 Solar cable UL approval

    Solar cable is a special cable used in solar power generation systems, mainly for DC voltage terminals, lead-in connections of power generation equipment and inter-component convergence connections, up to DC 1.8kv for photovoltaic power generation equipment systems. It is weather-resistant, cold-resistant, high-temperature-resistant, friction-resistant, UV-resistant and ozone-resistant, with working life of at least 25 years.


    Description:
    (1) Long-term working temperature of cable conductor -40℃~125℃
    (2) The maximum temperature of the cable conductor does not exceed 280℃ during short circuit (the longest duration does not exceed 5s)
    (3) It has excellent heat resistance, cold resistance, oil resistance, ultraviolet resistance, ozone resistance, low smoke, halogen-free, low toxicity and flame retardant.
    (4) Thermal shrinkage ≤1%;  20000h thermal life test, elongation at break ≤50%.
    (5) The bending radius of the cable should not be less than the following requirements: 4D when D<8mm, 6D when D≥8mm (Note D is the outer diameter of the cable)
